CNS-LFP12V Series
Rate capacity: 50Ah-300Ah
Rate voltage: 12V
Cyclelife :>3000 cycles 80% DOD
Applications:
Energy Storage
Solar-Wind Power System / City Grid (On/Off) / Community and Household
Back-up System and UPS
Telcom Base / CATV system / Computer Server Center / Medical Instrumnt / Military Equipment
Other Applications
Security and Electronics / Mobile POS, Mining Lihgt / Torch / LED Light / Emergency Light
RV Motorhome /Golf Carts Battery / Boat Marine Yachts / Electric Skateboard
LED Backup / Engine Starting Battery,etc.
Item No :
CNS-LFP12V SeriesOrder(MOQ) :
50 pcsPayment :
T/TProduct Origin :
ChinaColor :
BlackShipping Port :
ShenzhenLead Time :
1 weekWeight :
6.5-37 Kg12V Lead Acid Replacement Battery ( LiFePO4 )
Description
LiFePO4 12.8V Battery Pack: a high-performance and environmentally-friendly solution. With quality assurance, lightweight design, high power output, fast charging, safety, and long life, this battery pack is the ideal choice for your needs.
CNS-LFP12V Series lithium battery has the outstanding features of large capacity per unit weight, high discharge power, fast charging, long cycle life, and high stability under high temperature and high heat environment. The product has a 80% depth of discharge. One important advantage over other lithium-ion chemistries is its thermal and chemical stability, which improves the battery safety. With the combination of LiFePO4, the product can perform a more stable redox reaction and faster ion migration. The other is that it offers a longer cycle life. It has a very constant discharge voltage which can always stay stable until the cell is exhausted. This allows the cell to deliver virtually full power until it is discharged, and it can greatly simplify or even eliminate the need for voltage regulation circuitry. The battery back is impact-proof and is tested to be able to sustain heavy external shocks without risk of explosion.
Features:
FAQ:
Q: Are CONSNANT LiFePO4 lithium batteries safe?
A: Yes, CONSNANT LiFePO4 lithium batteries are safe. They use stable LiFePO4 chemistry and have CE certification. The batteries include a Battery Management System (BMS) for protection.
Q: How should I store CONSNANT LiFePO4 lithium batteries?
A: Store CONSNANT LiFePO4 batteries at around 50% charge in a temperature range of 10℃ to 35℃ (50℉ to 95℉) with a humidity of 45% to 75%. Cycle the batteries every 6 months when stored for long periods.
Q: Can I charge CONSNANT LiFePO4 lithium batteries in cold weather?
A: Yes, our professionals test the batteries for quality assurance.
Q: Are the batteries tested before shipping?
A: Yes, you can charge CONSNANT LiFePO4 lithium batteries with solar panels. Ensure the charge controller matches your solar array's voltage and current output.
Q: What is your lead time?
A: It depends on the order amount and the season you place the order. Usually we can ship within 7-15 days for small amount,and about 30 days for large amount.
Q: What is your warranty?
A: We offer 3-5 years warranty for all our battery pack.we ensure at least 4000 cycle life for the LiFePO4 battery pack, which means,after 3000 cycle 80% DOD,there will still around 60% capacityt left.You can use it for at least 5 years for normal 1 time charge and discharge everyday.
Technical Parameters:
Model |
LFP1250 | LFP1260 | LFP12100 | LFP12120 | LFP12150 | LFP12200 | LFP12300 |
Electrical Parameter | |||||||
Rate voltage | 12.8V | ||||||
Rate capacity | 50AH | 60AH | 100AH | 120AH | 150AH | 200AH | 300AH |
Energy | 768Wh | 768Wh | 1280Wh | 1536Wh | 1920Wh | 2560Wh | 3840Wh |
Cyclelife | >3000 cycles 80% DOD | ||||||
Operating Parameter | |||||||
Charge voltage | 14.2V | ||||||
Charge current | 25A | 30A | 50A | 60A | 75A | 100A | 150A |
Max. charge current | 50A | 60A | 100A | 120A | 150A | 200A | 200A |
Discharge cut-off voltage | 10V | ||||||
Discharge current | 25A | 30A | 50A | 60A | 75A | 100A | 150A |
Max. discharge current | 50A | 60A | 100A | 120A | 150A | 200A | 200A |
Max. pulse discharge current(<0.3S) |
150A | 180A | 300A | 360A | 450A | 600A | 600A |
Discharge temperature | -20~55℃ | ||||||
Charge temperature | 0~55℃ | ||||||
Storage temperature | -10~45℃ | ||||||
Optional items | |||||||
Display | LCD/Bluetooth | ||||||
Series or parallel connection | 4S or 4P | ||||||
Mechanical Parameter | |||||||
Terminal | M8 | ||||||
Weight | 6.5KG | 8KG | 12.5KG | 16KG | 17KG | 25KG | 37KG |
Dimension(LxWxH)mm | 198x166x170 | 260x168×209 | 330x173x215 | 406x173×236 | 483x170x240 | 522x240×218 | 520x269×220 |
Standard | |||||||
Certification | CE |
